When purchasing a replacement garage door or adding one to a new home, it’s important to understand standard garage door sizes. Given the variety in dimension combinations, it’s difficult to label any one option as a standard garage door size, but some sizes are certainly more common than others. Here is the standard garage door size based on height and width: 2
- 7-8 feet high by 8-10 feet wide for a single garage door
- 7-8 feet high by 16-18 feet wide for a double garage door
- 10-14 feet high by 10-14 feet wide for a RV garage door
What’s Ahead
- Garage Door Designs
- Single Garage Doors
- Double Garage Doors
- RV Doors
- Combination Garage Doors
- Custom Garage Doors
- Measuring Your Garage Door
- Ordering A New Garage Door
Garage Door Design Options
The garage door size you need depends on the size and layout of your garage itself. Blueprints for garages vary from small spaces designed for a single vehicle to larger, standard 2 car garage door sizes, to multiple-vehicle options.
If you bought an existing home, this decision had likely already been made for you. But, when building or remodeling a home, several factors must be considered, including:
- Personal preference, style, and needs are based on a number of vehicles.
- Aesthetics and how the garage façade will affect the appearance of your home.
- Practicality and the cost of maintaining multiple doors and an opener system.
Standard Garage Door Measurements
| Common Heights | Common Widths | |
|---|---|---|
| Single Doors | 7 or 8 feet | 8, 9, or 10 feet |
| Double Doors | 7 or 8 feet | 16 or 18 feet |
| RV Doors | 10, 12, or 14 feet | 10, 12, or 14 feet |
| Notes | Door heights available in 3-inch increments, aside from 7-feet, 3-inches | Door widths available in 2-inch increments |
Single Car Garage Door Dimensions
Suited for smaller garage spaces with room for only one vehicle, single garage doors most commonly measure either 7 or 8 feet in height and 8, 9, or 10 feet in width. The doors are suited for a single standard-sized car, SUV, truck, or van.
Two Car Garage Door Dimensions
Homes with multiple-vehicle garages will most commonly use a double-door option, measuring 7 or 8 feet in height and 16 or 18 feet in width. This option is also popular with those planning to use a portion of their garage as a workshop or storage space.
RV Garage Door Dimensions
Large doors are available for those with specialized needs, such as parking several vehicles or an RV. These oversized garage doors tend to be 10, 12, or 14 feet in both height and width.
Combination Garage Doors
As seen in the graphic above, many garages use a combination of either multiple single doors or a single and double door. While these garage door designs offer more space and flexibility, they also require maintenance and upkeep of at least two separate openers and garage door systems.
Custom Garage Doors
If you’re having trouble finding the right pre-fabricated door to meet your needs, Door 48 can assist with the design and creation of custom wood and steel garage doors. Visit the Door 48 website or call 844-568-0114 for more information.
Standard Garage Door Thickness
Standard garage door panels are roughly 1/8 inches thick. Depending on the utilization of your garage, you may or may not need insulation. If you spend time in your garage, you might consider installing insulation. Properly installed insulation can keep your garage 12 degrees warmer in winter and 25 degrees cooler in the summer which can also positively impact energy costs.
How to Measure Your Garage Door
If you’re considering purchasing a new garage door, we’re happy to visit and measure your door to ensure you’re looking at the right options. But, if you’re the do-it-yourself type, here are step-by-step instructions for measuring your garage door and ensuring your garage can accommodate an opener and the door in both the open and closed positions.
1. Measure the width and height of the door opening – called the “rough opening” – to the closest inch. This will be approximately the same size as your door.
2. Measure the space to the left and right of the opening – called the “sideroom.” Most vertical track systems require 3.75 inches on each side. Some systems require even more space, at 5.5 inches.
3. Measure the distance between the top of the opening and the ceiling – called the “headroom.” Standard systems require 12 inches of headroom, and most openers require an additional 3 inches of clearance.
4. Measure the distance from the garage door opening to the back wall of the garage – called the “backroom.” You will need backroom equal to the door height plus 18 inches, possibly more based on opener installation.
Ordering Your New Garage Door
Once you’ve determined your garage door size and are ready to move forward with purchasing a new door, we’ll be here to help. Call (844) 236-8448, and a member of our team will be available to assist.
Please be aware, though, that as of summer 2021, supply chain issues such as material availability, labor shortages, and shipping delays continue to affect product availability and installation timelines. Even common-sized garage doors may require special ordering. Our team is doing everything we can to ensure you receive the best product in a timely manner, but we ask for and appreciate your continued patience.
